石英晶体谐振器
石英晶体谐振器是什么？
石英晶体谐振器是利用电信号频率等于石英晶片固有频率时晶片因压电效应而产生谐振现象的原理制成的器件，是晶体振荡器和窄带滤波器等的关键元件。
石英晶体谐振器的特点与优点
- 石英晶体谐振器作为晶体振荡器中的谐振器，具有高精度频率、 严格的容差、长期稳定性和频率范围广等特点，并提供时钟源。
- 规格包括谐振频率、 谐振模式、 负载电容和串联电阻。
- 谐振频率操作中的振荡模式在基频或第三泛音下指定。
石英晶体谐振器的应用
- 移动电话
- 微处理器时钟电路
- GPS 时钟
- ISM 频段射频通信
RS 欧时为您提供了不同品牌的石英晶体谐振器，如Abracon、爱普生、瑞士微晶等多款不同规格、型号的产品供您挑选，从而满足不同的应用场景需求。
欢迎查看和订购欧时电子的石英晶体谐振器及相关产品，订购现货24小时内发货，线上下单满额免运费。
比较 产品详述 |
|---|
RMB2.558 个（每托盘 20 ） | RS PRO | 12MHz | 贴片 | 18pF | 表面安装 | 4 | 3.2mm | 2.5mm | 0.7mm | 3.2 x 2.5 x 0.7mm | ±20ppm | ±30ppm | 100Ω | -40°C | 85°C |
RMB1.36 个（每托盘 20 ） | RS PRO | 12MHz | 贴片 | 20pF | 表面安装 | 4 | 3.2mm | 2.5mm | 0.7mm | 3.2 x 2.5 x 0.7mm | ±20ppm | ±30ppm | 100Ω | -20°C | 70°C |
RMB1.047 个（每托盘 25 ） | RS PRO | 4.1943MHz | 贴片 | 18pF | - | 2 | 12mm | 3.8mm | 4.6mm | 12 x 3.8 x 4.6mm | ±30ppm | ±50ppm | 130Ω | -40°C | 85°C |
AKER | 11.0592MHz | 贴片 | 18pF | HC-49-US SMD | 2 | 13.5mm | 4.8mm | 4.6mm | 13.5 x 4.8 x 4.6mm | ±30ppm | ±50ppm | 50Ω | -40°C | 85°C | |
MERCURY | 16MHz | 贴片 | 12pF | SMD | 4 | 3.2mm | 2.5mm | 0.7mm | 3.2 x 2.5 x 0.7mm | ±30ppm | ±30ppm | 100Ω | -40°C | 85°C | |
IQD | 11.0MHz | 通孔 | 30pF | HC-49 | 2 | 11.05mm | 4.65mm | 13.46mm | 11.05 x 4.65 x 13.46mm | ±20ppm | ±30ppm | 35Ω | -10°C | 60°C | |
Euroquartz | 16MHz | 通孔 | 18pF | HC-49-4H | 2 | 10.77mm | 4.34mm | 3.5mm | 10.77 x 4.34 x 3.5mm | ±30ppm | ±3ppm | 40Ω | -40°C | 85°C | |
MERCURY | 8MHz | 贴片 | 12pF | SMD | 4 | 7mm | 5mm | 1.2mm | 7 x 5 x 1.2mm | ±30ppm | ±30ppm | 60Ω | -40°C | 85°C | |
Micro Crystal | 32.768kHz | 贴片 | 9pF | SMD | 2 | 2mm | 1.2mm | 0.6mm | 2 x 1.2 x 0.6mm | ±20ppm | - | 90kΩ | -40°C | 85°C | |
Epson | 24MHz | 贴片 | 12pF | TSX-3225 | 4 | 3.2mm | 2.5mm | 0.6mm | 3.2 x 2.5 x 0.6mm | ±10ppm | - | 40Ω | -40°C | 85°C | |
Micro Crystal | 32.768kHz | 贴片 | 9pF | SMD | 2 | 2mm | 1.2mm | 0.6mm | 2 x 1.2 x 0.6mm | ±20ppm | - | 90kΩ | -40°C | 85°C | |
MERCURY | 11.0592MHz | 通孔 | 18pF | HC-49-US | 2 | 10.7mm | 4.3mm | 3.5mm | 10.7 x 4.3 x 3.5mm | ±30ppm | ±50ppm | 40Ω | -40°C | 85°C | |
RMB1.904 个 (以毎袋：1000) | Abracon | 8MHz | 通孔 | 16pF | 柱状 | 2 | - | - | - | 8.0 x 3.0mm | ±30ppm | - | - | - | - |
Murata | 32MHz | 贴片 | 8pF | SMD | 4 | - | - | - | 2.0 x 1.6 x 0.7mm | - | - | - | - | - | |
Micro Crystal | 1MHz | 贴片 | 10pF | SMD | 2 | 5mm | 1.9mm | 0.9mm | 5 x 1.9 x 0.9mm | ±100ppm | - | 1.2kΩ | -40°C | 85°C | |
Micro Crystal | 32.768kHz | 贴片 | 12.5pF | SMD | 2 | 3.2mm | 1.5mm | 0.65mm | 3.2 x 1.5 x 0.65mm | ±20ppm | - | 70kΩ | -40°C | 125°C | |
Abracon | 16MHz | 贴片 | 15pF | SMD | 4 | - | - | - | 5 x 3.2 x 1.5mm | ±2.5ppm | - | - | - | - | |
Abracon | 0.032768MHz | 通孔 | 12.5pF | 圆柱形 | 2 | - | - | - | 16.3 x 3.1mm | ±20ppm | - | - | - | - | |
QANTEK | 16MHz | 贴片 | 12pF | SMD | 4 | 5mm | 3.2mm | 1mm | 5 x 3.2 x 1mm | ±10ppm | ±20ppm | 50Ω | -40°C | 85°C | |
MERCURY | 25MHz | 通孔 | 18pF | HC-49-US | 2 | 10.7mm | 4.3mm | 3.5mm | 10.7 x 4.3 x 3.5mm | ±30ppm | ±50ppm | 40Ω | -40°C | 85°C |
